Strongarm Mobile Station Operator Interface Terminal

MOBILE STATION

Strongarm’s mobile workstations provide the flexibility to share equipment across multiple process areas, helping reduce costs and maximize utilization. Every workstation is engineered to order and customized for your specific application, delivering a compact, ergonomic design with the capabilities you need. Power options include a tethered AC connection or a rechargeable battery for uninterrupted operation.

Turnkey Integration
Our integration services simplify deployment by installing client-supplied equipment or sourcing, integrating, and wiring all required components before shipment. The result is a fully assembled, tested, and ready-to-deploy turnkey solution that minimizes installation time and accelerates implementation.

FEATURES

  • Mobile, operator-friendly interface
  • Sealed lead acid or lithium phosphate battery options
  • Un-interruptable power source (UPS) options for AC tethered units provide temporary power while unplugged
  • NEMA Type 4/12 (powder-coated steel, see color options) or Type 4X (304/316L stainless steel)
  • Enclosures are fabricated from 14 gauge carbon (4/12) or stainless steel (4X)
  • Side, rear, or front flush and inset door options for access to printers, scanners, and other internally integrated devices
  • Static or slide-out tray options for barcode printers, laser printers, or component mounting.
  • Display sizes range from 15” to 24”, available with or without a touch screen
  • Touch screen options to meet any environmental requirements (See also: Touch Screen Technologies)
  • A variety of keyboard and input devices available, including Strongarm’s patented stainless steel mouse
  • Aluminum subpanels on the rear door for mounting terminal blocks, PCs, KVMs, power supplies, and other components extenders
  • Intrinsically safe non-incendive options are available for Class I Division 2 areas
  • IP64, IP65 & IP66 configurations available
  • UL 508A Listed (File No E225791)
Strongarm Mobile Station Operator Interface Terminal
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System
Strongarm Mobile Station Operator Interface System

CUSTOM SOLUTIONS

Strongarm has the expertise and experience to customize, design, and build the ideal operator interface to suit your application. Our extensive design resources enable us to engineer every feature you’ll need before in-house fabrication, assembly, finishing, testing, quality assurance, and on-time delivery. Since 1990, we’ve designed, built, and delivered over 500,000 products on time for our customers.

SPECIFICATIONS

ENCLOSURE SPECS

NEMA Type Type 4/12/4X
Construction Precision laser-cut and continuously TIG welded with all seams ground smooth
Material NEMA 4/12: 14g carbon steel low carbon sheet
NEMA 4X: 14g 304/316L stainless steel sheet
Finishing NEMA 4X: RA35 brushed satin finish
NEMA 12: Powder coated steel
NEMA 4: Primed and powder coated steel
Wheels Thermoplastic rubber on polyolefin or Performa conductive rubber non-marking wheels (custom wheels also available)
Casters 304 or 316 stem or swivel and fixed top plate casters with or without locks
Gaskets Oil resistant silicone foam door gaskets on NEMA 4/4X
Poron door gaskets on NEMA 12
Latches NEMA 4/4X: 1/4 turn stainless steel slotted latches, optional stainless steel compression latches
NEMA 12: 1/4 turn chrome slotted latch with zinc die black housing
Hinges NEMA 4/4X/12: 316 stainless steel concealed hinges
Agency Approval UL 508A, Rohs, Reach
Ingress Protection IP54, IP64, IP65 & IP66
UL Listed - RoHS Compliant

OTHER OPTIONS

Panel Mount Displays

Strongarm Industrial Panel Mount Display Options

Keyboards & Pointers

Strongarm Industrial Keyboard and Pointer Options

Computers & KVMs

Strongarm Industrial Computer and KVM Options

Accessories

Strongarm Accessory Options

Click chart below for NEMA Type 4/12 powder coated steel color options.

Strongarm Stock Color Chart

CUSTOM DESIGN GALLERY
