Strongarm Mini Console Pedestal Station Operator Interface Terminal

MINICONSOLE™

The MiniConsole is the ideal workstation for any process area. The keyboard and display mimic the ergonomics of a laptop but in an industrial package. Choose from swivel, fixed, and mobile mounting options. NEMA Type 4 and 12 units are manufactured from powder carbon steel, and NEMA Type 4X units are constructed from either 304 or 316L stainless steel.

Choose from a large selection of premium Strongarm-built industrial displays and industry-proven keyboards and input devices.

Strongarm can install and integrate all user-supplied components into your system, or we can procure, integrate, and wire any specified components before shipment, providing a 100% turnkey installation-ready system.

FEATURES

  • Operator friendly and compact interface solution is ideal for process control areas
  • Mobile, fixed, swivel, and telescoping post options
  • Display sizes range from 15” to 24” and are available with or without touch screens
  • Touch screen options are available for all environments (See also: Touch Screen Technologies)
  • A variety of keyboard and input devices available, including Strongarm’s patented stainless steel mouse
  • NEMA Type 4/12 (powder-coated steel, see color options) or NEMA Type 4X (304/316L stainless steel)
  • Enclosures are fabricated from 14 gauge carbon (4/12) or stainless steel (4X)
  • Internal slim subpanel for mounting terminal blocks, microcomputers, or KVM extenders
  • Intrinsically safe non-incendive options available for Class I Division 2 areas
  • IP64, IP65 & IP66 configurations available
  • UL 508A Listed (File No E225791)

MOUNTING OPTIONS

POST OPTIONS

Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Industrial Panel Mount Display

DISPLAY OPTIONS

  • Strongarm Industrial Display sizes range from 12” – 24”
  • Clip-in or stud mounting options available
  • Precision milled stainless steel or aluminum bezels ensure industrial reliability
  • Rated for high and low operating temperatures (-4º to 140ºF / -20º to 60ºC)
  • High shock (50G) and vibration resistant (1.5g)
  • Long-life LED backlights to ensure trouble-free 24/7 operation
  • Multiple touchscreen options, polycarbonate, and safety glass options for non-touch displays
Strongarm Industrial Keyboard and Pointer Options

KEYBOARD OPTIONS

  • Built to survive the industrial environment
  • Sealed membrane or rubber keyboard options
  • Resistant to dust, dirt, water, and corrosive liquids
  • >1 million switching cycles
  • Durable pointer selections to choose from, including Strongarm’s stainless steel mouse
  • NEMA 4/12/4X
  • Ergonomic with a compact footprint
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal
Strongarm Mini Console Operator Interface Terminal

CUSTOM SOLUTIONS

Strongarm has the expertise and experience to customize, design, and build the ideal operator interface to suit your application. Our extensive design resources enable us to engineer every feature you’ll need before in-house fabrication, assembly, finishing, testing, quality assurance, and on-time delivery. Since 1990, we’ve designed, built, and delivered over 400,000 products on time for our customers.

SPECIFICATIONS

ENCLOSURE SPECS

NEMA Type Type 4/12/4X
Construction Precision laser-cut and continuously TIG welded with all seams ground smooth
Material NEMA 4X: 14g 304/316L stainless steel
NEMA 4/12: 14g carbon steel low carbon
Finishing NEMA 4X: RA35, stainless steel
 brushed satin finish
NEMA 12: Powder coated steel
NEMA 4: Primed and powder coated steel
Door Options Cover plate on rear for display access and spring assisted flip top access to computer storage
Gaskets NEMA 4/4X: Oil resistant silicone foam door gaskets
NEMA 12: Poron door gaskets
Latches NEMA 4/4X: 1/4 turn stainless steel slotted latches
NEMA 12: 1/4 turn chrome slotted latch with zinc die black housing
Ingress Protection IP54, IP64, IP65 & IP66
Agency Approval UL 508A, Rohs, Reach
UL Listed - RoHS Compliant

OTHER OPTIONS

Panel Mount Displays

Strongarm Industrial Panel Mount Display Options

Keyboards & Pointers

Strongarm Industrial Keyboard and Pointer Options

Computers & KVMs

Strongarm Industrial Computer and KVM Options

Accessories

Strongarm Accessory Options

Click chart below for NEMA Type 4/12 powder coated steel color options.

Strongarm Stock Color Chart

CUSTOM DESIGN GALLERY
