LARGE SCREEN DISPLAY SYSTEMS

Supersize your operator interface solution with Strongarm’s large screen display systems. Our large format display systems provide outstanding “viewability” for marquee graphics, digital signage, production control, and feature environmental and physical protection to ensure a trouble-free long-life. Mounting options include wall, ceiling, or pedestal mount and can be supplied with or without an optional yoke to provide tilt. NEMA Type 4 and 12 units are fabricated from powder-coated carbon steel, and Type 4X units are fabricated from 304 or 316L stainless steel. Like all of Strongarm’s products, our large screen display systems are engineered to order, allowing us to modify your system to meet your specific needs and requirements.

FEATURES

  • Display sizes range from 32” to 75” and are available with or without touch screens
  • Interface options include VGA, DVI, HDMI, and DisplayPort
  • NEMA Type 4/12 (powder-coated steel, see color options) or Type 4X (304/316L stainless steel)
  • Wall, ceiling, or pedestal mounting options available
  • Enclosures are fabricated from 14 gauge sheet
  • Aluminum subpanel on the rear door for mounting terminal blocks, computers, KVM’s, and other components
  • Front or rear door options available with 1/4 turn latches
  • Optional purge systems allow for installation in any Division 1 or Division 2 hazardous area
  • UL 508A Listed (File No E225791)
  • IP64, IP65 & IP66 configurations available
Strongarm Large Screen Display Systems
Strongarm Large Screen Display Systems
Strongarm Large Screen Display Systems
Strongarm Large Screen Display Systems
Strongarm Large Screen Display Systems
Strongarm Large Screen Display Systems
Strongarm Large Screen Display Systems
Strongarm Large Screen Display Systems

CUSTOM SOLUTIONS

Strongarm has the expertise and experience to customize, design, and build the ideal operator interface to suit your application. Our extensive design resources enable us to engineer every feature you’ll need before in-house fabrication, assembly, finishing, testing, quality assurance, and on-time delivery. Since 1990, we’ve designed, built, and delivered over 500,000 products on time for our customers.

DISPLAYS

  • Big and bright active matrix TFT displays
  • Available in 32″, 42”, 47″, 55”, or 70” sizes
  • One-touch automatic adjustment
  • Infrared touchscreens available for all sizes (See also: Touch Screen Technologies)
  • 3-year warranty on displays and electronics, 1-year warranty on touchscreens

SPECIFICATIONS

NEMA Type Type 4/12/4X
Construction Precision laser-cut and seam welded
Material NEMA 4/12: 14g carbon steel
NEMA 4X: 14g 304/316L stainless steel
Finishing NEMA 4X: RA35 brushed satin finish
NEMA 12: Powder coated steel
NEMA 4: Primed and powder coated steel
Gaskets NEMA 4/4X: Oil resistant silicone foam door gaskets
NEMA 12: Poron door gaskets
Latches NEMA 4/4X: 1/4 turn stainless steel slotted latches
NEMA 12: 1/4 turn chrome slotted latch with zinc die black housing
Hinges NEMA 4/4X/12: Rear door: 316 stainless steel lift-off hinges
Reinforcement Folded and welded stiffener
Agency Approval UL 508A, Rohs
Ingress Protection IP54, IP64, IP65 & IP66
UL Listed - RoHS Compliant

OTHER OPTIONS

Computers & KVMs

Strongarm Industrial Computer and KVM Options

Accessories

Strongarm Accessory Options

Click chart below for NEMA Type 4/12 powder coated steel color options.

Strongarm Stock Color Chart

CUSTOM DESIGN GALLERY
