INDUSTRIAL PANEL PC
Strongarm’s rugged 24″ widescreen Industrial Panel PC is engineered to thrive in the harshest industrial environments. Built for durability and performance, this powerful HMI solution features a scratch-resistant IP65-ratedtouchscreen and a robust enclosure, offeringprotection against dust, water, and impact.
With an extended operating temperature range, our Industrial Panel PCoperates in extreme heat or cold, making it ideal for heavy-dutymanufacturing, food and beverage processing, pharmaceuticals,energy, and other mission-critical industrial applications.
Our Industrial Panel PCis part of Strongarm’sVulcan™ Series of ruggedand durable panel PCs.
FEATURES
- Rugged versatility for any application
- Hardened scratch-resistant touchscreen (See also: Touchscreen Technologies)
- -31° to 140°F (-35° to 60°C) operating temperature range
- 100mm VESA mount, panel mount, or rig mount
- NEMA 4/4X Class I/Division 1 and Class I/Division 2 and IP65 rated (front) for hazardous area use
SPECIFICATIONS
COMPUTER
| Processor | Latest generation Intel® quad-core processor | |
| Memory | Up to 32 GB DDR4-2133 SODIMM non-ECC memory | |
| Hard Drive | Dual solid-state, field replaceable | |
| Additional Removable Storage | Compact Flash | |
| Additional Connections | Audio in/out (stereo) | |
| Connection Type | Screw connection terminal blocks | |
| Operating System | Microsoft Windows® | |
| MTBF | 80 Khrs @ 65ºC |
DISPLAY
| Native Resolution | 24″ LED: 1920 x 1080 FHD | |
| Brightness | > 1000 NIT | |
| Touchscreen | Hardened resistive (> Mohs 5 glass surface) anti-scratch GFG touch screen | |
| Viewing Angle | 170º (left to right) 160º (up and down) | |
| Response Time | 5 ms | |
| Maximum Colors | 16.7 million (8-bit) | |
| Aspect Ratio | 16:9 |
INPUTS/OUTPUTS
| Connections (Panel PC) | (3) USB, (2) 1GB ethernet, (2) RS232/485 serial, VGA, speaker, HDMI | |
| Connections (Display only) | (1) USB, (2) RS232 for optional touchscreen, VGA, HDMI |
POWER
| Input Voltage | 100-240 VAC – 50/60 Hz or 10-36 VDC auto ranging | |
| Power Consumption | 115W max | |
| DC Power In/Out | Reverse polarity protected | |
| DC/AC Voltage Protection | Transient voltage suppression |
ENVIRONMENTAL
| Operating Temperature | -35° to 60°C (-31° to 140°F) | |
| Storage Temperature | -40° to 85°C (-40° to 185°F) | |
| Shock | 10 G, 11 ms pulse, 3 axis | |
| Vibration | 2-13 Hz, displacement +/- 1.5mm, 3 axis 13-100 Hz acceleration +/- 10 m/sec2 (1g), 3 axis |
STANDARDS & CERTIFICATIONS
| NEMA Rating | NEMA 4/4X, IP65 | |
| Hazardous Area | ATEX/IECEx: II 3 G Ex nA IIC T3 Gc, Ex nA IIC T3 Gc, 35°C≤Ta≤+60°C Gc North American (UL): Class I, Division 2, Groups A, B, C, D Class I, Zone 2, Group IIC, T3 |
|
| Green Product | RoHS (2002/95-EC, 2011/65/EU), WEEE (2002/96-EC) |
ADDITIONAL INFO
| Weight | 37 lb (16.78 kg) | |
| Overall Dimensions | 25.25″ x 16.00″ x 4.47″ (641mm x 406mm x 114mm) | |
| Mounting | VESA 100, panel mount (optional), or rig mount (optional), and other custom mounting options available | |
| Cable Entry | (1) M20 316SS area-rated cable gland (10-14 mm) (4) M20 316SS area-rated cable gland (7-12 mm) |
WARRANTY & SERVICE
| Serviceability | Site serviceable parts (request manual for detailed list) | |
| Warranty | 3 Year (1 year on LCD panel) |
DIMENSIONS
CUSTOM SOLUTIONS
Strongarm has the expertise and experience to customize, design, and build the ideal operator interface to suit your application. Our extensive design resources enable us to engineer every feature you’ll need before in-house fabrication, assembly, finishing, testing, quality assurance, and on-time delivery. Since 1990, we’ve designed, built, and delivered over 500,000 products on time for our customers.
